Description
| General Specifications | ||||||
| Name/Model | CP13 | Hardware solution | op amp: JRC5532 | |||
| color | Sky blue/Black and white/Red and silver | Weight | About 310g | |||
| Dimensions | About 120×88.3×31.8mm |
|
Volume knob | |||
| Jitter | ≤ 0.2% | Flywheel | Φ30.4mm oversize pure copper flywheel | |||
| Motor |
|
|
|
|||
| Supported cassette types: |
|
|
|
|||
| Adaptive impedance |
|
|||||
| Buttons and Ports | ||||||
| Buttons | Physical buttons (Play*1+Rewind*1+Fast ward*1+Pause*1） |
|
Type-C USB (charging port) | |||
| Headphone output | Standard 3.5mm |
|
Volume adjustment knob | |||
| Power Supply Parameters | ||||||
| Power Supply | Supports DC 5V/≥2A |
|
1800mAh polymer battery | |||
| Charging time | About 3H (5V 2A adapter) |
|
＞268 days | |||
| Battery life and test conditions | ||||||
| 3.5mm headphone out: ≥13 hours | ||||||
| Audio input | Native cassette playback | Gain | N/A | |||
| Volume | 40mV output | charging switch |
|
|||
| Loading | 32 Ω | |||||
| Audio Parameters | ||||||
| Parts of performance and parameters of headphone output (3.5mm) | ||||||
| output amplitude | L+R≥250mV+250mV (32Ω) | THD+N & Noise | ≤ 3.5% | |||
| Output power 1 | L+R≥1.3mW+1.3mW (16Ω) | SRN | ≥55dB (A-weighted) | |||
| Output power 2 | L+R≥2mW+2mW (32Ω) | Noise floor | ＜0.55mV (A-weighted) | |||
